Cast resin straight joint 1GRL

Products

1GR4

Nexans ref.

  • Resin type: ISBP
  • Cable Diameter, range: 30 - 55 mm
  • Length: 440 mm



1GR5

Nexans ref.

  • Resin type: ISBP
  • Cable Diameter, range: 50 - 75 mm
  • Length: 650 mm



1GR6

Nexans ref.

  • Resin type: ISBP
  • Cable Diameter, range: 50 - 88 mm
  • Length: 810 mm



1GRL1

Nexans ref.

  • Resin type: ISBE
  • Cable Diameter, range: 8 - 26 mm
  • Length: 190 mm



1GRL2

Nexans ref.

  • Resin type: ISBE
  • Cable Diameter, range: 14 - 32 mm
  • Length: 275 mm



1GRL3

Nexans ref.

  • Resin type: ISBE
  • Cable Diameter, range: 23 - 39 mm
  • Length: 360 mm



Description

Description

Standards

  • International
    CENELEC HD 623; EN 50393

Application

the 1GRL cast resin straight joints are designed to connect various types of low voltage cables with polymeric (PVC, XLPE) or paper insulation.
The joints provide excellent mechanical protection and good electrical insulation.
Available with PUR or Epoxy resins.
The joints can be energized immediately after installation.
Joints can also accommodate armored cables with the addition of an armor kit.



Kit contents

  • Injection molded shells
  • 2 chamber resin bag / or in cans
  • Sealing tape
  • Instruction manual
  • (Armor kit for cables w. armor)

1GRL Other options

*Standard resin: EPOXY for 1GRL1, 1GRL2 and 1GRL3
*Standard resin: PUR with fillers for 1GRL4, 1GRL5 and 1GRL6

##image:94140:center##

Characteristics

Characteristics

Electrical characteristics

Electrical characteristics

Maximum operating voltage
1 kV
